Iseki TF243

Last Updated: June 2024

Overview

The Iseki TF243 is a robust compact utility tractor that's designed to cater to a range of agricultural tasks. With a durable 4x4 MFWD 4WD chassis and 23.7 hp diesel engine, this tractor is well-suited for various operations from tilling to loading. Its power comes from a liquid-cooled 3-cylinder engine, with a displacement of 89.3 cubic inches, capable of maximum power at 2500 RPM. Furthermore, the TF243 operates with a manual transmission, offering 9 forward and 3 reverse gears to tackle different terrains and tasks. The tractor's weight of 1940 lbs and dimensions, with a length of 113.8 inches, a width of 47.2 inches, and a height of 77.4 inches, provide a stable and manageable work vehicle. Its ground clearance of 14.2 inches paired with standard ag tires allows for sufficient maneuverability in varied soil conditions. However, detailed specifics about the steering system, hydraulics, PTO speeds, and hitch capabilities are not specified. All in all, the Iseki TF243 represents a practical solution for small scale farming or utility work, given its size and power.
Show more...

Key Specifications

Category: Utility

Power Output: 23.7

Transmission: Manual

Drive Type: 4WD

Operating Weight: 1940

Fuel Type: Diesel

Iseki TF243 vs. Similar Tractors

Power Output
Below Average
Greater than 15% of similar tractors.
Operating Weight
Below Average
Greater than 16% of similar tractors.

Technical Specifications

Engine

Manufacturer
Iseki
Model
E3CF-B
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
3
Displacement (ci)
89.3
Bore (in)
3.39
Stroke (in)
3.3
Rated RPM
2500
Power Output (hp)
23.7

Transmission

Type
Manual
Forward Gears
9
Reverse Gears
3
Total Gears
12

Dimensions

Length (in)
113.8
Width (in)
47.2
Height (in)
77.4
Operating Weight (lb)
1940

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
Unknown, assuming Category 0 due to 'Rear Type: 0'
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric Starter
Brake Type
-
Hydraulic System Type
-
