Iseki TD4450

Last Updated: June 2024

Overview

The Iseki TD4450 is equipped with an Isuzu C240 four-cylinder liquid-cooled diesel engine, capable of delivering 48 horsepower at 2600 rated RPM. With a displacement of 144.6 cubic inches and measurements of 3.39 inches in bore and 4.02 inches in stroke, it provides sufficient torque for various farming tasks. The TD4450's transmission is a synchromesh type offering 18 forward gears and 6 reverse gears, engaged via a 260mm dry disc clutch. Dimensions of this tractor include a length of 134.2 inches, a width of 61 inches, and a height of 90.2 inches at the steering wheel. The model comes in both 2WD and 4WD configurations, with respective weights of 3679 pounds and 3965 pounds, showing the tractor's robust build for a range of agricultural operations. The TD4450 sits on a wheelbase of 78.7 inches and has a ground clearance of 16.5 inches, which along with its open center hydraulic system type, positions it as a practical option for farmers seeking versatility.
Show more...

Key Specifications

Power Output: 48

Transmission: Synchromesh

Operating Weight: 3679 (2WD), 3965 (4WD)

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
Isuzu
Model
C240
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
4
Displacement (ci)
144.6
Bore (in)
3.39
Stroke (in)
4.02
Rated RPM
2600
Power Output (hp)
48

Transmission

Type
Synchromesh
Forward Gears
18
Reverse Gears
6
Total Gears
-

Dimensions

Length (in)
134.2
Width (in)
61
Height (in)
90.2
Operating Weight (lb)
3679 (2WD), 3965 (4WD)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
-
Drive Type
-
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
-
Hitch Category
I
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
Open Center
