Iseki TC11

Last Updated: June 2024

Overview

The Iseki TC11 is a sub-compact utility tractor that features a four-wheel drive chassis. It is powered by a 10.2 horsepower, two-cylinder, diesel Iseki E255 engine that is liquid-cooled. The engine has a displacement of 33.8 cubic inches with a bore and stroke of 2.76 inches and 2.835 inches, respectively, and operates at a rated speed of 2500 RPM. This model comes with a gear-driven transmission that has 6 forward gears and 2 reverse gears. With a wheelbase of 41.3 inches, the TC11 has an overall length of 75 inches, width of 36 inches, and height of 68.1 inches. It weighs 1025 pounds and has a ground clearance of 9.5 inches. The tractor rides on standard agricultural tires with front dimensions of 4.00-10 and rear dimensions of 7-14, which provide a stable and comfortable ride over various terrains.

Key Specifications

Category: Utility, Sub-Compact

Power Output: 10.2

Transmission: Gear

Drive Type: 4WD

Operating Weight: 1025

Fuel Type: Diesel

Image Gallery

Iseki TC11 Tractor

Iseki TC11 vs. Similar Tractors

Power Output

Poor

Greater than 0% of similar tractors.

Operating Weight

Poor

Greater than 7% of similar tractors.

Technical Specifications

Engine

Manufacturer: Iseki
Model: E255
Cooling Type: Liquid-cooled
Cylinder Orientation: -
Valve Configuration: -
Fuel Type: Diesel
Induction Type: Naturally aspirated
Cylinders: 2
Displacement (ci): 33.8
Bore (in): 2.76
Stroke (in): 2.835
Rated RPM: 2500
Power Output (hp): 10.2

Transmission

Type: Gear
Forward Gears: 6
Reverse Gears: 2
Total Gears: -

Dimensions

Length (in): 75
Width (in): 36
Height (in): 68.1
Operating Weight (lb): 1025

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x4 MFWD 4WD
Drive Type: 4WD
Steering Type: -
Coolant Capacity (qts): -
Front Tire Diameter (in): -
Front Tire Width (in): -
Rear Tire Diameter (in): -
Rear Tire Width (in): -
Front/Rear Rim Diameter (in): -
Tire Type: Agricultural
Manufacture - End Year: -
Hitch Type: -
Hitch Category: -
Hitch Position: -
Hitch Capacity (lb): -
Operator Station Type: -
Starter Type: Electric
Brake Type: -
Hydraulic System Type: -
