Iseki TA415

Last Updated: June 2024

Overview

The Iseki TA415 is a 4-wheel drive utility tractor, primarily designed for various farm tasks, including plowing, harrowing, and tilling. With a robust 4-cylinder liquid-cooled Isuzu 4JC1 diesel engine, it delivers a power output of 40.4 horsepower and has an engine displacement of 136.6 cubic inches. The tractor operates at a rated RPM of 2500 and starts with a 12-volt electric starter. A distinguishing feature of the TA415 is its wheelbase of 77.6 inches, supporting a balanced distribution of its operational weight of 4255 lbs. The tractor utilizes a 4x4 MFWD 4WD chassis for enhanced traction and has 16 forward and reverse gears, indicating a versatile transmission system, although the specific type of transmission is not specified in the data provided. The TA415 comes with standard agricultural tires, with the front tires noted as 8-18 and the rear tires sized 13.6-28, ideal for a variety of agricultural activities. The length of this tractor is noted at 134.3 inches, but its width and height are not specified. Though various other specifications such as hydraulic system type, PTO speeds, starter type, and additional features are not detailed, the Iseki TA415 remains a capable machine for farmers seeking a reliable workhorse for their daily operations.
Show more...

Key Specifications

Category: Utility

Power Output: 40.4

Drive Type: 4WD

Operating Weight: 4255

Fuel Type: Diesel

Iseki TA415 vs. Similar Tractors

Power Output
Average
Greater than 37% of similar tractors.
Operating Weight
Average
Greater than 39% of similar tractors.

Technical Specifications

Engine

Manufacturer
Isuzu
Model
4JC1
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
4
Displacement (ci)
136.6
Bore (in)
-
Stroke (in)
-
Rated RPM
2500
Power Output (hp)
40.4

Transmission

Type
-
Forward Gears
16
Reverse Gears
16
Total Gears
-

Dimensions

Length (in)
134.3
Width (in)
-
Height (in)
-
Operating Weight (lb)
4255

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural
Manufacture - End Year
-
Hitch Type
JIS1
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric Starter
Brake Type
-
Hydraulic System Type
-
