Iseki TA345

Last Updated: June 2024

Overview

The Iseki TA345 is a utility tractor equipped with an Iseki 4JE1 diesel engine, boasting 4 cylinders and a power output of 33.5 horsepower. With a displacement of 113.6 cubic inches, the engine is cooled by a liquid system and has a bore and stroke of 3.66 and 2.62 inches respectively. Operating at a rated RPM of 2600, the TA345 is capable of handling various tasks around the farm. This tractor has a substantial operating weight of 3750 pounds and dimensions measuring 129.9 inches in length, 60 inches in width, and 86.2 inches in height, with a wheelbase of 74.8 inches, providing stability and comfort during operation. The tires are 13.6-26 at the rear and a standard front tire size of 8-18, indicating its utility for a range of agricultural purposes. The tractor's robust construction and features are designed to meet the needs of modern farming activities, although specific data on some features is not available.
Show more...

Key Specifications

Power Output: 33.5

Operating Weight: 3750

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
Iseki
Model
4JE1
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
4
Displacement (ci)
113.6
Bore (in)
3.66
Stroke (in)
2.62
Rated RPM
2600
Power Output (hp)
33.5

Transmission

Type
-
Forward Gears
16
Reverse Gears
16
Total Gears
-

Dimensions

Length (in)
129.9
Width (in)
60
Height (in)
86.2
Operating Weight (lb)
3750

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
-
Drive Type
-
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
26
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
-
Hitch Category
JIS1
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
