Iseki TA325

Last Updated: June 2024

Overview

The Iseki TA325 is a tractor known for its balance of power and utility. It is powered by an Isuzu 4JF1 diesel engine with a liquid-cooling system that provides 31.6 horsepower at a rated RPM of 2800. The engine displacement is 91.3 cubic inches, with a bore and stroke measuring 2.96 and 3.31 inches respectively. The tractor features a robust drive system with 16 forward and reverse gears, facilitating versatile operation in varying agricultural tasks. It has a wheelbase of 73.6 inches and a ground clearance of 13.4 inches, which provides stability and maneuverability in diverse terrains. With its substantial operational weight of 3483 lbs and dimensions of 128 inches in length, 60 inches in width, and 75.6 inches in height, the TA325 is a tractor suited for a range of farm duties. Additionally, it has an agricultural-standard tire configuration with a rear tire size of 13.6-26.

Key Specifications

Power Output: 31.6

Operating Weight: 3483

Fuel Type: Diesel

Image Gallery

Iseki TA325 Tractor

Technical Specifications

Engine

Manufacturer: Isuzu
Model: 4JF1
Cooling Type: Liquid-cooled
Cylinder Orientation: -
Valve Configuration: -
Fuel Type: Diesel
Induction Type: Natural aspiration assumed
Cylinders: 4
Displacement (ci): 91.3
Bore (in): 2.96
Stroke (in): 3.31
Rated RPM: 2800
Power Output (hp): 31.6

Transmission

Type: -
Forward Gears: 16
Reverse Gears: 16
Total Gears: 32

Dimensions

Length (in): 128
Width (in): 60
Height (in): 75.6
Operating Weight (lb): 3483

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: -
Drive Type: -
Steering Type: -
Coolant Capacity (qts): -
Front Tire Diameter (in): -
Front Tire Width (in): -
Rear Tire Diameter (in): 26 (from tire size 13.6-26)
Rear Tire Width (in): 13.6 (from tire size 13.6-26)
Front/Rear Rim Diameter (in): Unknown (Complete size not provided, only rear tire diameter)
Tire Type: Agricultural standard tires inferred from "Standard tires (ag)"
Manufacture - End Year: -
Hitch Type: Category I
Hitch Category: Unknown (Specification for category provided, but detailed classification of 'I' not indicated)
Hitch Position: -
Hitch Capacity (lb): -
Operator Station Type: -
Starter Type: Electric
Brake Type: -
Hydraulic System Type: -
