Iseki TA320

Last Updated: June 2024

Overview

The Iseki TA320 is a utility tractor that ran on a 32 hp (23.9 kW) Isuzu 4FE1 diesel engine. With a robust 4-cylinder liquid-cooled system, the tractor is designed to handle a variety of tasks on the farm. The tractor's power is matched by a substantial weight range of 3109 to 3384 pounds and a wheelbase of 73 inches, ensuring stability and capability in challenging terrain. The TA320 features a large 91.5 cubic inch engine displacement. Both 2WD and 4WD models were available, with variances in standard tire sizes as per the need for better traction and performance on different grounds. It has a hefty length of 128.7 inches, a width of 60 inches, and a height of 75.6 inches, which includes the exhaust system. Rated at an engine speed of 2800 RPM, the tractor ensures sufficient power delivery for a range of applications. This model comes with a wide variety of front and rear treads, signifying its capacity to be customized for different farming needs. However, detailed specifics about the hydraulic system, PTO speeds, and hitch lift capacity are not provided in the given data.
Show more...

Key Specifications

Category: Utility

Power Output: 32

Operating Weight: 3109 to 3384

Fuel Type: Diesel

Iseki TA320 vs. Similar Tractors

Power Output
Below Average
Greater than 27% of similar tractors.
Operating Weight
Above Average
Greater than 84% of similar tractors.

Technical Specifications

Engine

Manufacturer
Isuzu
Model
4FE1
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
4
Displacement (ci)
91.5
Bore (in)
-
Stroke (in)
-
Rated RPM
2800
Power Output (hp)
32

Transmission

Type
-
Forward Gears
16
Reverse Gears
16
Total Gears
-

Dimensions

Length (in)
128.7
Width (in)
60
Height (in)
75.6
Operating Weight (lb)
3109 to 3384

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
-
Drive Type
-
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural
Manufacture - End Year
-
Hitch Type
JIS1
Hitch Category
-
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
