Iseki TA287

Last Updated: June 2024

Overview

The Iseki TA287 is a tractor that is powered by a three-cylinder, 27.6 horsepower Iseki E3ADI engine. It has a liquid-cooling system and a displacement of 91.4 cubic inches. The rated RPM for this engine is 2800, and it utilizes a diesel fuel system. With a wheelbase of 66.9 inches, the TA287 has dimensions that include a length of 120.9 inches, width of 53.4 inches, and varying heights depending on the presence of a cab or just the steering wheel. This tractor has a substantial weight range contingent upon its configuration, spanning from 2414 to 3064 pounds. It features 16 forward and reverse gears within its transmission system, hinting at its capability to handle a wide variety of tasks requiring different speeds and power. The TA287 is capable of accommodating both an open operator station and a cab version, providing flexibility depending on the operator's preference.

Key Specifications

Power Output: 27.6

Operating Weight: 3064 (4WD Cab), 2899 (2WD Cab), 2579 (4WD Open), 2414 (2WD Open)

Fuel Type: Diesel

Image Gallery

Iseki TA287 Tractor

Technical Specifications

Engine

Manufacturer: Iseki
Model: E3ADI
Cooling Type: Liquid-cooled
Cylinder Orientation: -
Valve Configuration: -
Fuel Type: Diesel
Induction Type: Naturally Aspirated
Cylinders: 3
Displacement (ci): 91.4
Bore (in): 3.43
Stroke (in): 3.31
Rated RPM: 2800
Power Output (hp): 27.6

Transmission

Type: -
Forward Gears: 16
Reverse Gears: 16
Total Gears: 32

Dimensions

Length (in): 120.9
Width (in): 53.4
Height (in): 78.5 (cab), 57.3 (steering wheel)
Operating Weight (lb): 3064 (4WD Cab), 2899 (2WD Cab), 2579 (4WD Open), 2414 (2WD Open)

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: -
Drive Type: -
Steering Type: -
Coolant Capacity (qts): -
Front Tire Diameter (in): -
Front Tire Width (in): -
Rear Tire Diameter (in): -
Rear Tire Width (in): -
Front/Rear Rim Diameter (in): -
Tire Type: Ag (Agricultural)
Manufacture - End Year: -
Hitch Type: -
Hitch Category: -
Hitch Position: -
Hitch Capacity (lb): -
Operator Station Type: Open, Cab
Starter Type: Electric
Brake Type: -
Hydraulic System Type: -
