Iseki TA267

Last Updated: June 2024

Overview

The Iseki TA267 is a utility tractor, well-suited for a variety of tasks around a small farm or rural property. With a liquid-cooled diesel engine generating 25.6 horsepower at 2500 RPM, this tractor provides the performance necessary for both power-demanding and routine agricultural work. Its Iseki E3ADI engine sports three cylinders with a displacement of 91.4 cubic inches, ensuring efficient operation with a stated engine oil capacity of 5.1 quarts. Notably, the tractor comes in both 2WD and 4WD configurations, catering to different terrain and task requirements. A significant feature includes its 16 forward and reverse gears, allowing for precise control and maneuverability. Two distinct operating weights and heights indicate the availability of either an open operator station or one with a cab, providing versatility for diverse weather conditions and operator preferences. The physical dimensions underline a design that aims to balance between being compact and offering substantial working capacity, with a length of 117.3 inches, a width of 52 inches, and a height of up to 78 inches with the cab option. Traction is maintained with standard agricultural tires, and while exact tire sizes for each wheel set are not listed, the tractor accommodates front tire sizes of 5.00-15 in 2WD models and 7-16 in 4WD models, with rear tires at 11.2-24 for both configurations.
Show more...

Key Specifications

Category: Utility

Power Output: 25.6

Drive Type: 4WD

Operating Weight: 3031

Fuel Type: Diesel

Iseki TA267 vs. Similar Tractors

Power Output
Below Average
Greater than 19% of similar tractors.
Operating Weight
Below Average
Greater than 25% of similar tractors.

Technical Specifications

Engine

Manufacturer
Iseki
Model
E3ADI
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
3
Displacement (ci)
91.4
Bore (in)
3.43
Stroke (in)
3.31
Rated RPM
2500
Power Output (hp)
25.6

Transmission

Type
-
Forward Gears
16
Reverse Gears
16
Total Gears
32

Dimensions

Length (in)
117.3
Width (in)
52
Height (in)
78
Operating Weight (lb)
3031

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
-
Drive Type
4WD
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
Open or Cab (assumed because Heights were listed separately)
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
