Iseki T8020

Last Updated: June 2024

Overview

The Iseki T8020 is a tractor that is driven by a powerful Isuzu 6BB1 diesel engine offering 78.4 horsepower and a displacement of 329.1 cubic inches. The tractor boasts a liquid-cooled engine system, keeping the engine at an optimal operating temperature, and an engine rated at 2200 RPM. It is equipped with two types of transmissions: a syncromesh and a creeper transmission, allowing for 12 forward and 4 reverse gears in the standard setup, and an extended gear range of 24 forward and 8 reverse gears with the creeper option. The tractor has a substantial length of 164 inches, a width of 78.2 inches, and a height of 104 inches. It is designed to support Ag tire configuration with a front tire size of 11.2-24 and rear tire size of 16.9-34. With an operating weight of 8179 pounds, it is built for various demanding tasks. The Iseki T8020 does not fit neatly into a single category of use but would likely be suitable for a wide range of mid to heavy-duty farming tasks. An electric starter ensures ease of ignition, and the rear Type II hitch is included for towing and tool attachment. Further details about the operator station, PTO, brakes, or hydraulic systems were not disclosed and remain unknown.
Show more...

Key Specifications

Power Output: 78.4

Transmission: Syncromesh, Creeper

Operating Weight: 8179

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
Isuzu
Model
6BB1
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
6
Displacement (ci)
329.1
Bore (in)
4.016
Stroke (in)
4.331
Rated RPM
2200
Power Output (hp)
78.4

Transmission

Type
Syncromesh, Creeper
Forward Gears
24
Reverse Gears
8
Total Gears
-

Dimensions

Length (in)
164
Width (in)
78.2
Height (in)
104
Operating Weight (lb)
8179

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
-
Drive Type
-
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
Rear Type II
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
