Iseki T6500

Last Updated: June 2024

Overview

The Iseki T6500 is a tractor that offers a blend of utility and performance for various agricultural tasks. It's powered by an Isuzu 4BB1 4-cylinder diesel engine with a liquid cooling system to ensure reliable operation under strenuous conditions. This engine provides a horsepower of 64.1, and at its rated RPM of 2200, is capable of handling a range of agricultural equipment. The tractor comes with a two-wheel drive (2WD) or four-wheel drive (4WD) option and is equipped with a gear transmission boasting 20 forward and 4 reverse gears. Its hydraulic system is an open-center type, and the hitch system belongs to Category II, which supports a variety of implements. Tire configurations vary between 2WD and 4WD versions to adapt to different farming needs. With a dry disc clutch and a multiple gear selection, operators can maintain precise control and maneuverability. The operating weights are 5423 lbs for the 2WD version and 5986 lbs for the 4WD version, indicating a robust and sturdy machine that can handle varying terrains with appropriate ground clearance. The overall dimensions of the tractor allow for good visibility and handling in different environments, from field operations to transport tasks.
Show more...

Key Specifications

Power Output: 64.1

Transmission: Gear

Drive Type: 2WD/4WD option

Operating Weight: 5423 (2WD), 5986 (4WD)

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
Isuzu
Model
4BB1
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
4
Displacement (ci)
219.4
Bore (in)
4.016
Stroke (in)
4.331
Rated RPM
2200
Power Output (hp)
64.1

Transmission

Type
Gear
Forward Gears
20
Reverse Gears
4
Total Gears
-

Dimensions

Length (in)
142.1
Width (in)
72.4
Height (in)
96.9
Operating Weight (lb)
5423 (2WD), 5986 (4WD)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
-
Drive Type
2WD/4WD option
Steering Type
-
Coolant Capacity (qts)
5
Front Tire Diameter (in)
Unknown (2WD), Unknown (4WD)
Front Tire Width (in)
Unknown (2WD), Unknown (4WD)
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural
Manufacture - End Year
-
Hitch Type
Category II three-point hitch
Hitch Category
Category 3
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric 12 volt
Brake Type
-
Hydraulic System Type
Open center
