Iseki T6010

Last Updated: June 2024

Overview

The Iseki T6010 is a utility tractor that's powered by an Isuzu 4BC2 diesel engine with a displacement of 199.4 cubic inches. This engine provides 60 horsepower and is liquid-cooled to ensure efficient operation. The tractor's power is managed by a 12-speed syncromesh transmission, offering a range of 12 forward gears and 4 reverse gears for versatile operation in different agricultural tasks. Its 4x2 2WD chassis and power steering afford the operator with essential maneuverability and ease of use, particularly on flat terrain. The tractor is designed with a Category II rear hitch, and although specifics like tire sizes, operating weight, and dimensions are not provided, the T6010's foundation makes it suitable for a variety of utility tasks on a farm or homestead. Equipped with basic essentials such as an electric starter and a dual dry element air cleaner, the Iseki T6010 prioritizes reliability and straightforward operation.
Show more...

Key Specifications

Category: Utility

Power Output: 60

Transmission: Syncromesh

Drive Type: 2WD

Fuel Type: Diesel

Iseki T6010 vs. Similar Tractors

Power Output
Average
Greater than 58% of similar tractors.

Technical Specifications

Engine

Manufacturer
Isuzu
Model
4BC2
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Direct injection
Cylinders
4
Displacement (ci)
199.4
Bore (in)
4.016
Stroke (in)
3.937
Rated RPM
2300
Power Output (hp)
60

Transmission

Type
Syncromesh
Forward Gears
12
Reverse Gears
4
Total Gears
-

Dimensions

Length (in)
-
Width (in)
-
Height (in)
-
Operating Weight (lb)
-

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
Category II
Hitch Category
-
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
