Iseki AT280

Last Updated: June 2024

Overview

The Iseki AT280 is a compact utility tractor equipped for a variety of tasks thanks to its robust 4x4 MFWD 4WD chassis and powerful steering system. At its core, the AT280 is powered by a 27.6 horsepower Iseki E3CG diesel engine that operates at a max RPM of 2500. The three-cylinder, liquid-cooled engine with a displacement of 100.5 cubic inches ensures efficient operation and solid performance for different agricultural needs. It has a dry disc clutch and a transmission that includes 16 forward gears, although the number of reverse gears is not specified. The tractor offers a sizeable wheelbase of 66 inches for stability and features a weight range from 3020 to 3351 pounds, indicating models with ROPS and cab variations. The AT280's size and weight make it suitable for tasks that require finesse rather than brute force, making it a good match for small farms and specialty applications.

Key Specifications

Category: Utility

Power Output: 27.6

Drive Type: 4WD

Operating Weight: 3351 (assuming cab weight is the operating weight)

Fuel Type: diesel

Image Gallery

Iseki AT280 Tractor

Iseki AT280 vs. Similar Tractors

Power Output

Below Average

Greater than 22% of similar tractors.

Operating Weight

Below Average

Greater than 29% of similar tractors.

Technical Specifications

Engine

Manufacturer: Iseki
Model: E3CG
Cooling Type: liquid-cooled
Cylinder Orientation: -
Valve Configuration: -
Fuel Type: diesel
Induction Type: -
Cylinders: 3
Displacement (ci): 100.5
Bore (in): 3.43
Stroke (in): 3.62
Rated RPM: 2500
Power Output (hp): 27.6

Transmission

Type: -
Forward Gears: 16
Reverse Gears: -
Total Gears: 16

Dimensions

Length (in): 120.1
Width (in): 54.3
Height (in): 77.8 (assuming the cab height is the overall height)
Operating Weight (lb): 3351 (assuming cab weight is the operating weight)

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x4 MFWD 4WD
Drive Type: 4WD
Steering Type: power
Coolant Capacity (qts): -
Front Tire Diameter (in): -
Front Tire Width (in): -
Rear Tire Diameter (in): -
Rear Tire Width (in): -
Front/Rear Rim Diameter (in): -
Tire Type: Standard tires (ag)
Manufacture - End Year: -
Hitch Type: Category 3 (assuming rear based on "Rear Type: I")
Hitch Category: -
Hitch Position: Rear (assumed from "Rear Type: I")
Hitch Capacity (lb): -
Operator Station Type: Unknown (both ROPS and cab versions exist)
Starter Type: electric
Brake Type: -
Hydraulic System Type: -
