International Harvester TD-8 82 Series

Last Updated: June 2024

Overview

The International Harvester TD-8 82 Series is a diesel-powered tractor known for its robust performance, particularly in challenging environments. This model comes with a 4-cylinder International Harvester BD-281 engine that is liquid-cooled with a displacement of 281 cubic inches, capable of delivering 62.5 horsepower at a rated RPM of 1600. Equipped with a 5-forward-and-1-reverse gear transmission system and a dry disc clutch, the TD-8 ensures smooth shifting and control. The transmission and engine specs suggest that this tractor is designed to perform a variety of pulling and stationary work, which would benefit from its significant power and torque of 220 lb-ft at 1200 RPM. The tractor’s operating weight of 11500 pounds combined with its compact dimensions (Length: 115.8 inches, Width: 68 inches, Height: 67.5 inches) make it suitable for a variety of working conditions. However, the specific type of work for which this tractor is most suitable is not clear due to missing details in the provided data.
Show more...

Key Specifications

Power Output: 62.5

Transmission: Gear

Operating Weight: 11500

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
International Harvester
Model
BD-281
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
4
Displacement (ci)
281
Bore (in)
4.125
Stroke (in)
5.25
Rated RPM
1600
Power Output (hp)
62.5

Transmission

Type
Gear
Forward Gears
5
Reverse Gears
1
Total Gears
-

Dimensions

Length (in)
115.8
Width (in)
68
Height (in)
67.5
Operating Weight (lb)
11500

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
-
Drive Type
-
Steering Type
-
Coolant Capacity (qts)
25.8
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric Starter
Brake Type
-
Hydraulic System Type
-
