International Harvester FG

Last Updated: June 2024

Overview

The International Harvester FG is a row-crop tractor known for its traditional 4x2 2WD chassis and manual steering capabilities. It is outfitted with a gear transmission featuring 4 forward and 1 reverse gears. The tractor is powered by a choice of either a 20hp International Harvester 2.0L 4-cylinder kerosene engine or a MWM 2.4L 2-cylinder diesel engine. The kerosene engine features a bore and stroke of 3.15x4.00 inches, while the diesel engine has a bore and stroke of 3.937x5.906 inches. Rated RPMs for these engines are 1650 and 1500, respectively. With a substantial operating weight of 3860 lbs and a solid wheelbase of 76.8 inches, the FG model showcases the robustness expected from a row-crop tractor of its era. However, it does start with a hand-crank system, which harkens back to an older generation of tractor technology.
Show more...

Key Specifications

Category: Row Crop

Power Output: 20

Transmission: Gear

Drive Type: 2WD

Operating Weight: 3860

Fuel Type: Kerosene, Diesel

Image Gallery

International Harvester FG Tractor International Harvester FG Tractor International Harvester FG Tractor International Harvester FG Tractor International Harvester FG Tractor International Harvester FG Tractor International Harvester FG Tractor International Harvester FG Tractor

International Harvester FG vs. Similar Tractors

Power Output
Poor
Greater than 1% of similar tractors.
Operating Weight
Below Average
Greater than 18% of similar tractors.

Technical Specifications

Engine

Manufacturer
International Harvester, MWM
Model
2.0L 4-cyl kerosene, 2.4L 2-cyl diesel
Cooling Type
-
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Kerosene, Diesel
Induction Type
Naturally aspirated
Cylinders
4, 2
Displacement (ci)
124.7, 143.4
Bore (in)
3.15, 3.937
Stroke (in)
4.00, 5.906
Rated RPM
1650, 1500
Power Output (hp)
20

Transmission

Type
Gear
Forward Gears
4
Reverse Gears
1
Total Gears
-

Dimensions

Length (in)
-
Width (in)
-
Height (in)
-
Operating Weight (lb)
3860

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Manual
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag Front, Ag Rear
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Hand-crank
Brake Type
-
Hydraulic System Type
-
