International Harvester D-436

Last Updated: September 2024

Overview

The International Harvester D-436 is a sturdy diesel tractor built for farm work. It has a liquid-cooled engine with four cylinders, made by International Harvester. This engine can produce 39 horsepower at 1900 rpm, which is good for many farming tasks. The tractor uses an Agriomatic transmission with 8 forward gears and 2 reverse gears, giving the driver plenty of options for different jobs.

This tractor is compact but strong. It measures 115.25 inches long, 64.5 inches wide, and 61 inches tall. The D-436 weighs 3142 pounds, making it stable for fieldwork. It has a category 2/1 hitch, which lets it connect to many farm tools. The tractor starts easily with an electric starter. With its 14.5-quart coolant capacity, the D-436 can work for long hours without overheating. Overall, the International Harvester D-436 is a reliable tractor that can handle various farm tasks efficiently.
Show more...

Key Specifications

Power Output: 39 hp (29.1 kW)

Transmission: Agriomatic

Operating Weight: 3142 lb (1425 kg)

Fuel Type: Diesel

International Harvester D-436 vs. Similar Tractors

Power Output

The Power Output for the International Harvester D-436 is Average. It is greater than 31% of similar Utility tractors in our database.

Horsepower distribution of Utility tractors

(across 6.6K+ tractors in our database)

Operating Weight

The Operating Weight for the International Harvester D-436 is Below Average. It is greater than 24% of similar Utility tractors in our database.

Operating weight distribution of Utility tractors

(across 6.4K+ tractors in our database)

Engine Displacement

The Engine Displacement for the International Harvester D-436 is Average. It is greater than 34% of similar Utility tractors in our database.

Engine displacement distribution of Utility tractors

(across 1K+ tractors in our database)

Engine Rated RPM

The Engine Rated RPM for the International Harvester D-436 is Poor. It is greater than 9% of similar Utility tractors in our database.

Engine rated RPM distribution of Utility tractors

(across 1K+ tractors in our database)

Technical Specifications

Engine

Manufacturer
International Harvester
Model
DD-148
Cooling Type
Liquid-cooled
Fuel Type
Diesel
Cylinders
4
Displacement
148 ci (2.4 L)
Bore
3.44 in (87.3 mm)
Stroke
4.00 in (101.6 mm)
Rated RPM
1900
Power Output
39 hp (29.1 kW)

Transmission

Type
Agriomatic
Forward Gears
8
Reverse Gears
2
