International Harvester 834

Last Updated: June 2024

Overview

The International Harvester 834 is a row-crop tractor that was built to accommodate various agricultural tasks. It features a 4x2 2WD chassis and is powered by a 4-cylinder International Harvester D-246 diesel engine with a displacement of 246.1 cubic inches. The engine has direct injection, with a rated power output of 81.8 hp at 2300 RPM, demonstrating valuable performance for farmers. The tractor uses a manual transmission with 12 forward and 4 reverse gears, facilitating versatility and control when operating in varying field conditions. The International 834 comes with power steering for easier maneuverability. It has an operating weight of 7518 pounds in its 2WD configuration and measures 131.5 inches long, with a wheelbase of 83.5 inches. The height to the steering wheel is 65 inches, indicating a moderately sized tractor suitable for a range of activities. With standard ag tires, the 834 offers dependable traction in different soil conditions.
Show more...

Key Specifications

Category: Row Crop

Power Output: 81.8

Transmission: Manual

Drive Type: 2WD

Operating Weight: 7518 (2WD)

Fuel Type: Diesel

International Harvester 834 vs. Similar Tractors

Power Output
Below Average
Greater than 12% of similar tractors.
Operating Weight
Above Average
Greater than 83% of similar tractors.

Technical Specifications

Engine

Manufacturer
International Harvester
Model
D-246
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Direct injection
Cylinders
4
Displacement (ci)
246.1
Bore (in)
3.94
Stroke (in)
5.06
Rated RPM
2300
Power Output (hp)
81.8

Transmission

Type
Manual
Forward Gears
12
Reverse Gears
4
Total Gears
-

Dimensions

Length (in)
131.5 (2WD)
Width (in)
74.4
Height (in)
65 (to steering wheel)
Operating Weight (lb)
7518 (2WD)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Power
Coolant Capacity (qts)
20.6
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Standard tires (ag)
Manufacture - End Year
-
Hitch Type
Category II
Hitch Category
Category 3
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
