International Harvester 786B

Last Updated: September 2024

Overview

The International Harvester 786B is a powerful tractor designed for serious farm work. It features a 6-cylinder diesel engine made by International Harvester. This engine, called the D-310, has a displacement of 310 cubic inches and can produce 100 horsepower. The tractor uses liquid cooling to keep the engine running smoothly, even during tough jobs.

One of the standout features of the 786B is its transmission. It has a two-speed power shift system with 16 forward gears and 8 reverse gears. This gives farmers lots of options for different tasks and speeds. The tractor is big and strong, measuring 155.9 inches long and 101.6 inches wide. It weighs 11,354 pounds, which helps it handle heavy loads. The 786B comes with agricultural tires and a Category 3 hitch, making it ready for a wide range of farm equipment. It also has an electric starter for easy operation.
Show more...

Key Specifications

Power Output: 100 hp (74.6 kW)

Transmission: Two-speed power shift

Operating Weight: 11354 lb (5150 kg)

Fuel Type: Diesel

International Harvester 786B vs. Similar Tractors

Power Output

The Power Output for the International Harvester 786B is Above Average. It is greater than 73% of similar Utility tractors in our database.

Horsepower distribution of Utility tractors

(across 5.8K+ tractors in our database)

Operating Weight

The Operating Weight for the International Harvester 786B is Above Average. It is greater than 79% of similar Utility tractors in our database.

Operating weight distribution of Utility tractors

(across 5.7K+ tractors in our database)

Engine Displacement

The Engine Displacement for the International Harvester 786B is Above Average. It is greater than 75% of similar Utility tractors in our database.

Engine displacement distribution of Utility tractors

(across 1K+ tractors in our database)

Engine Rated RPM

The Engine Rated RPM for the International Harvester 786B is Average. It is greater than 60% of similar Utility tractors in our database.

Engine rated RPM distribution of Utility tractors

(across 1K+ tractors in our database)

Technical Specifications

Engine

Manufacturer
International Harvester
Model
D-310
Cooling Type
Liquid-cooled
Fuel Type
Diesel
Induction Type
Direct injection
Cylinders
6
Displacement
310 ci (5.1 L)
Bore
3.88 in (98.4 mm)
Stroke
4.38 in (111.1 mm)
Rated RPM
2400
Power Output
100 hp (74.6 kW)

Transmission

Type
Two-speed power shift
Forward Gears
16
Reverse Gears
8
