International Harvester 464

Last Updated: June 2024

Overview

The International Harvester 464 is a 2WD utility tractor that was manufactured by International Harvester from 1973 to 1978. It is equipped with either a 2.9 L, 175 cu·in four-cylinder gasoline engine or a 2.9 L, 179 cu·in four-cylinder diesel engine, both having a hydrostatic power steering system. The transmission is synchromesh with 8 forward and 4 reverse gears. The 464 model has an open operator station with an optional ROPS and is capable of using a range of attachments thanks to the three-point hitch system at the rear. It has a weight range of 4100 to 5130 pounds and can be identified by its notably wide, adjustable front and rear tread.
Show more...

Key Specifications

Category: Utility

Power Output: 45

Transmission: Synchromesh

Drive Type: 2WD

Operating Weight: 5130

Fuel Type: Gasoline, Diesel

Image Gallery

International Harvester 464 Tractor International Harvester 464 Tractor International Harvester 464 Tractor International Harvester 464 Tractor International Harvester 464 Tractor International Harvester 464 Tractor International Harvester 464 Tractor International Harvester 464 Tractor International Harvester 464 Tractor International Harvester 464 Tractor

International Harvester 464 vs. Similar Tractors

Power Output
Average
Greater than 43% of similar tractors.
Operating Weight
Average
Greater than 44% of similar tractors.

Technical Specifications

Engine

Manufacturer
International Harvester
Model
C-175 (Gasoline), D-179 (Diesel)
Cooling Type
Liquid-cooled
Cylinder Orientation
Inline
Valve Configuration
-
Fuel Type
Gasoline, Diesel
Induction Type
Naturally aspirated
Cylinders
4
Displacement (ci)
175 ci (Gasoline), 179 ci (Diesel)
Bore (in)
3.54 (Gasoline), 3.86 (Diesel)
Stroke (in)
4.41 (Gasoline), 5.08 (Diesel)
Rated RPM
2400
Power Output (hp)
45

Transmission

Type
Synchromesh
Forward Gears
8
Reverse Gears
4
Total Gears
-

Dimensions

Length (in)
132.7
Width (in)
65.7
Height (in)
-
Operating Weight (lb)
5130

Power Take-Off (PTO)

PTO Type
Independent
PTO Speed 1 (rpm)
540
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Hydrostatic power
Coolant Capacity (qts)
13 (Gasoline), 12 (Diesel)
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural
Manufacture - End Year
1978
Hitch Type
Three-Point Hitch (presumed from Rear Type: I)
Hitch Category
Category 1
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
Open operator station or ROPS (optional)
Starter Type
Electric Starter
Brake Type
Independent hydraulic wet disc
Hydraulic System Type
-
