IMT 555

Last Updated: June 2024

Overview

The IMT 555 is a utility tractor produced by Industrija Motora Traktora, commonly known as IMT. It features a manual steering system and operates through a 2WD, 4x2 chassis configuration. Powered by a 50 hp liquid-cooled diesel engine with a displacement of 203.2 cubic inches, the tractor provides robust performance for various farm operations, including plowing, tilling, and hauling. The engine model IM-034 operates at a rated RPM of 2000 and provides both strength and efficiency with its natural aspiration system. The transmission of the IMT 555 is a gear type, with 6 forward and 2 reverse gears, allowing the operator to choose the optimal operating speed. Its physical dimensions include a length of 137.2 inches, a width of 66.9 inches, and a height to the exhaust top of 88.6 inches, with an operating weight of 4200 pounds. This gives the tractor a sturdy presence in the field, while the clearance levels under the axles ensure it's well-suited for varied terrain. The tractor also features an electric starter and a two-point hitch system. Additional specifications such as PTO speeds, brake and hydraulic system types, or operator station configurations are not provided.
Show more...

Key Specifications

Category: Utility

Power Output: 50

Transmission: Gear

Drive Type: 2WD

Operating Weight: 4200

Fuel Type: Diesel

IMT 555 vs. Similar Tractors

Power Output
Average
Greater than 49% of similar tractors.
Operating Weight
Average
Greater than 38% of similar tractors.

Technical Specifications

Engine

Manufacturer
IMT
Model
IM-034
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Natural aspiration (assumed due to lack of specification regarding turbocharging or supercharging)
Cylinders
4
Displacement (ci)
203.2
Bore (in)
3.6
Stroke (in)
5
Rated RPM
2000
Power Output (hp)
50

Transmission

Type
Gear
Forward Gears
6
Reverse Gears
2
Total Gears
8

Dimensions

Length (in)
137.2
Width (in)
66.9
Height (in)
88.6 (assuming this is the overall height to the top of exhaust as it is the taller measurement)
Operating Weight (lb)
4200

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Manual
Coolant Capacity (qts)
12.7
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
Three-Point Hitch (inferred from "Rear Type: II")
Hitch Category
Unknown (cannot assume Category 3 from "Rear Type: II" as it could be either Category 2 or 3)
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
