IMT 5130

Last Updated: June 2024

Overview

The IMT 5130 tractor is designed with a focus on durability and function. Featuring a 135 hp turbocharged diesel engine with a displacement of 353.7 cubic inches, it is well-equipped for challenging agricultural tasks. The chassis is a classic 4x2 wheel configuration with two-wheel drive (2WD). Its power steering and gear-driven transmission offering 10 forward gears and 2 reverse gears allow for smooth operation and ease of use. This model stands tall with a height of 112.6 inches at the exhaust and has a robust operating weight of 13,318 lbs, indicating strong build quality and capability for its class. The tractor is outfitted with agricultural tires, hinting at its primary utilization in farming operations, and its liquid-cooled engine system ensures reliability under strenuous work conditions.
Show more...

Key Specifications

Power Output: 135

Transmission: Gear

Drive Type: 2WD

Operating Weight: 13318

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
IMR
Model
TS 46/T
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
6
Displacement (ci)
353.7
Bore (in)
3.87
Stroke (in)
5
Rated RPM
2250
Power Output (hp)
135

Transmission

Type
Gear
Forward Gears
10
Reverse Gears
2
Total Gears
-

Dimensions

Length (in)
190.2
Width (in)
86.7
Height (in)
112.6
Operating Weight (lb)
13318

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2
Drive Type
2WD
Steering Type
Power Steering
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
Category II
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
Cab
Starter Type
-
Brake Type
-
Hydraulic System Type
-
