IMT 2070

Last Updated: June 2024

Overview

The IMT 2070 tractor is a robust and versatile machine designed to meet the requirements of a variety of farming tasks. Equipped with a powerful 75.5 horsepower engine and a 4-wheel drive chassis, it offers considerable power and traction. The hydrostatic power steering contributes to the ease of maneuverability, while the synchro transmission with 10 forward and 2 reverse gears enables efficient operation across different terrains. This model features a 4-cylinder 4045DF270 diesel engine with a displacement of 276.4 cubic inches and a bore and stroke of 4.19 inches and 5.00 inches, respectively. Rated RPM for the engine is 2300. The tractor has a substantial operating weight of 9261 pounds, which ensures stability and allows for heavy-duty applications. Measurement-wise, the tractor has a length of 140.2 inches and a height of 106.3 inches, with standard ag tires measuring 12.4-24 in the front and 18.4-30 in the rear. The straightforward design and reliable performance of the IMT 2070 make it a valuable asset for various farming operations.
Show more...

Key Specifications

Power Output: 75.5

Transmission: Synchro

Drive Type: 4WD

Operating Weight: 9261

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
IMT
Model
4045DF270
Cooling Type
-
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
4
Displacement (ci)
276.4
Bore (in)
4.19
Stroke (in)
5
Rated RPM
2300
Power Output (hp)
75.5

Transmission

Type
Synchro
Forward Gears
10
Reverse Gears
2
Total Gears
-

Dimensions

Length (in)
140.2
Width (in)
-
Height (in)
106.3
Operating Weight (lb)
9261

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Hydrostatic Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
