IMR Rakovica R 35 DV

Last Updated: June 2024

Overview

The IMR Rakovica R 35 DV is a utility-class four-wheel-drive (4WD) tractor, designed to serve a variety of roles typically found on a farm or rural property. With a liquid-cooled, three-cylinder diesel engine capable of delivering 33.5 horsepower and featuring direct injection, it is well-suited for a range of tasks. The engine is engineered to operate at a rated RPM of 3000, with a displacement of 91.3 cubic inches. The tractor's torque is substantial for its size, generating 70.8 lb-ft at 1800 RPM. It sports a synchronized gear transmission with 8 forward gears and 4 reverse gears and operates with a dry disc clutch. With a wheelbase of 66.5 inches and an operating weight of 3858 lbs, combined with a ground clearance of 9.1 inches, this tractor offers stability and versatility. It is equipped with a 12 volt electric starter. The specifics regarding its chassis and dimensions render it suitable for a variety of agricultural tasks.
Show more...

Key Specifications

Category: Utility

Power Output: 33.5

Transmission: Synchronized Gear

Drive Type: 4WD

Operating Weight: 3858

Fuel Type: Diesel

IMR Rakovica R 35 DV vs. Similar Tractors

Power Output
Below Average
Greater than 29% of similar tractors.
Operating Weight
Average
Greater than 35% of similar tractors.

Technical Specifications

Engine

Manufacturer
IMR Rakovica
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Direct-injection
Cylinders
3
Displacement (ci)
91.3
Bore (in)
3.31
Stroke (in)
3.54
Rated RPM
3000
Power Output (hp)
33.5

Transmission

Type
Synchronized Gear
Forward Gears
8
Reverse Gears
4
Total Gears
-

Dimensions

Length (in)
116.1
Width (in)
52.8
Height (in)
-
Operating Weight (lb)
3858

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
