Hurlimann XA 606

Last Updated: September 2024

Overview

The Hurlimann XA 606 is a 2WD tractor with a 4x2 chassis. It has a manual transmission with 20 forward gears and 10 reverse gears, giving farmers lots of options for different tasks. The tractor uses hydrostatic power steering, which makes it easy to control.

Under the hood, the XA 606 has a SAME diesel engine with 3 cylinders. The engine has 60 horsepower and runs at 2350 RPM. It's built to be strong, with a peak torque of 151.2 lb-ft at 1400 RPM. The tractor is 93.7 inches tall and weighs 5666 pounds, making it sturdy for farm work. It has a wheelbase of 83.1 inches, which helps it stay stable on different terrains.
Show more...

Key Specifications

Power Output: 60 hp (44.7 kW)

Transmission: Manual

Drive Type: 2WD

Operating Weight: 5666 lb (2570 kg)

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
SAME
Fuel Type
Diesel
Cylinders
3
Displacement
183 ci (3.0 L)
Bore
4.13 in (105.0 mm)
Stroke
4.55 in (115.5 mm)
Rated RPM
2350
Power Output
60 hp (44.7 kW)

Transmission

Type
Manual
Forward Gears
20
Reverse Gears
10

Drivetrain

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Hydrostatic power
