Hurlimann H-657 XA

Last Updated: September 2024

Overview

The Hurlimann H-657 XA is a powerful 2WD tractor designed for farm work. It has a SAME diesel engine with 4 cylinders and 72 horsepower. The engine is strong, with a displacement of 244.1 cubic inches. It can run at 2350 RPM and has a high torque of 203.6 lb-ft at 1400 RPM.

This tractor is built for versatility, with 24 forward gears and 12 reverse gears. This gives farmers lots of options for different tasks. The H-657 XA has hydrostatic power steering, making it easy to control. It's a good size for many farms, measuring 151.6 inches long and 96.1 inches tall. The tractor weighs 5865 pounds, which helps it handle tough jobs. It has a wheelbase of 88.2 inches, giving it stability in the field.
Show more...

Key Specifications

Power Output: 72 hp (53.7 kW)

Drive Type: 2WD

Operating Weight: 5865 lb (2660 kg)

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
SAME
Fuel Type
Diesel
Cylinders
4
Displacement
244 ci (4.0 L)
Bore
4.13 in (105.0 mm)
Stroke
4.55 in (115.5 mm)
Rated RPM
2350
Power Output
72 hp (53.7 kW)

Transmission

Forward Gears
24
Reverse Gears
12

Drivetrain

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Hydrostatic power
