Hurlimann H-488T

Last Updated: June 2024

Overview

The Hurlimann H-488T is a utility tractor designed for a variety of agricultural tasks. With a SAME turbocharged diesel engine, the tractor offers a solid 88 horsepower (65.6 kW) which is well-suited for daily farm activities. The Hurlimann H-488T features a 4x2 chassis and two-wheel drive system, complemented by hydrostatic power steering for improved maneuverability. The tractor's 20-speed transmission allows for a variety of speed and power settings to adapt to different working conditions. The engine's torque is rated at 238.2 lb-ft at 1300 RPM, ensuring enough pulling power when needed. The H-488T stands tall at 103.54 inches and has a length of 160.63 inches, which provides a sturdy and reliable platform for various attachments and implements. Its notable weight of 7706 lbs ensures stability during operation. It has substantial tires, with the front being 13.6 inches wide and 28 inches in diameter, while the rear tires are wider at 18.4 inches and have a diameter of 34 inches, suited for different types of terrain.
Show more...

Key Specifications

Category: Utility

Power Output: 88

Drive Type: 2WD

Operating Weight: 7706

Fuel Type: Diesel

Hurlimann H-488T vs. Similar Tractors

Power Output
Above Average
Greater than 75% of similar tractors.
Operating Weight
Average
Greater than 55% of similar tractors.

Technical Specifications

Engine

Manufacturer
SAME
Model
-
Cooling Type
Liquid
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement (ci)
244.08
Bore (in)
4.1338
Stroke (in)
4.5472
Rated RPM
2500
Power Output (hp)
88

Transmission

Type
-
Forward Gears
20
Reverse Gears
20
Total Gears
-

Dimensions

Length (in)
160.63
Width (in)
-
Height (in)
103.54
Operating Weight (lb)
7706

Power Take-Off (PTO)

PTO Type
Optional Transmission or Live PTO (Assumed based on spec pattern)
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2
Drive Type
2WD
Steering Type
Hydrostatic power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
28
Front Tire Width (in)
13.6
Rear Tire Diameter (in)
34
Rear Tire Width (in)
18.4
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
