Hurlimann H-305 XE

Last Updated: June 2024

Overview

The Hurlimann H-305 XE is a utility tractor known for its versatility and dependability. Designed to perform a variety of tasks, it is equipped with a robust air-cooled, Same 1000.3 A, 3-cylinder diesel engine that produces 49.6 horsepower at a rated RPM of 2350. Air-cooled systems such as the one on this tractor are typically more straightforward to maintain than liquid-cooled systems, making it a suitable choice for various weather conditions and less intensive cooling requirements. With multiple transmission options, including mechanical shuttle and creeper types, the H-305 XE offers up to 24 forward and 12 reverse gears, enabling it to handle diverse field conditions effectively. Its power steering feature provides increased maneuverability, essential in confined spaces or when performing tasks that require precision. The tractor is built on a 4x2 two-wheel-drive chassis, and the base operating weight ranges between 4277 pounds for the 2WD version and 4740 pounds for the 4WD variant. The Hurlimann H-305 XE has an electric starter, but details regarding the hitch type, PTO speeds, and hydraulic system type are not provided. Additional features have not been specified in the provided data. This model showcases Hurlimann's commitment to making robust and efficient tractors and is a valuable asset for a variety of agricultural tasks.
Show more...

Key Specifications

Category: Utility

Power Output: 49.6

Transmission: Mechanical shuttle / Creeper

Drive Type: 2WD

Operating Weight: 4277 (2WD) / 4740 (4WD)

Fuel Type: Diesel

Hurlimann H-305 XE vs. Similar Tractors

Power Output
Average
Greater than 48% of similar tractors.
Operating Weight
Excellent
Greater than 96% of similar tractors.

Technical Specifications

Engine

Manufacturer
SAME
Model
1000.3 A
Cooling Type
Air-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
3
Displacement (ci)
183.1
Bore (in)
4.134
Stroke (in)
4.54
Rated RPM
2350
Power Output (hp)
49.6

Transmission

Type
Mechanical shuttle / Creeper
Forward Gears
24
Reverse Gears
12
Total Gears
-

Dimensions

Length (in)
133.1
Width (in)
64.6
Height (in)
-
Operating Weight (lb)
4277 (2WD) / 4740 (4WD)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag (Agricultural)
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
