Hurlimann H-1500 SX

Last Updated: June 2024

Overview

The Hurlimann H-1500 SX is a steadfast two-wheel drive (2WD) tractor, often recognized by its distinctive 4x2 wheel configuration. It thrives under the power of a 150 hp turbo diesel engine produced by SAME, with a displacement of 366.12 cubic inches and a 6-cylinder arrangement. The engine fine-tunes its performance with a notable 481.7 lb-ft torque at 1450 RPM and a 2350 RPM rated speed. This tractor boasts an 18-speed transmission, providing ample variability to tackle different tasks efficiently. Measuring 183.9 inches long and 113.4 inches in height, the H-1500 SX presents a grand stature in the field, with a commanding operating weight of 13,450 lbs. The hydrostatic power steering facilitates easier handling, even when the tractor is operating at full capacity. Standard ag tires are mounted on the tractor, with different specifications for the front (480/70R30) and the rear (580/70R38), indicating a versatility for agricultural settings.
Show more...

Key Specifications

Power Output: 150

Drive Type: 2WD

Operating Weight: 13450

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
SAME
Model
-
Cooling Type
-
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbo
Cylinders
6
Displacement (ci)
366.12
Bore (in)
4.1338
Stroke (in)
4.5472
Rated RPM
2350
Power Output (hp)
150

Transmission

Type
-
Forward Gears
18
Reverse Gears
18
Total Gears
-

Dimensions

Length (in)
183.9
Width (in)
-
Height (in)
113.4
Operating Weight (lb)
13450

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Hydrostatic Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
