Huber 35-70

Last Updated: June 2024

Overview

The Huber 35-70 is a standard-tread tractor designed for a variety of agricultural tasks. With a manual steering system and a chassis configured as 4x2 2WD, it facilitates movement over uneven agricultural land. The tractor is powered by a 4-cylinder, kerosene-fueled, liquid-cooled engine offering a displacement of 1321 cubic inches. This sizable engine operates at a rated speed of 550 RPM and maintains its operating temperature using a substantial 380-quart coolant capacity. Designed for reliability and the ability to handle heavy farm tasks, the Huber 35-70 was built during an era when the focus was on straightforward, durable farm equipment capable of handling the rigors of day-to-day farm work.
Show more...

Key Specifications

Category: Utility, Standard Tread

Drive Type: 2WD

Fuel Type: Kerosene

Technical Specifications

Engine

Manufacturer
Huber
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Kerosene
Induction Type
Naturally Aspirated
Cylinders
4
Displacement (ci)
1321
Bore (in)
7.25
Stroke (in)
8
Rated RPM
550
Power Output (hp)
-

Transmission

Type
-
Forward Gears
-
Reverse Gears
-
Total Gears
-

Dimensions

Length (in)
-
Width (in)
-
Height (in)
-
Operating Weight (lb)
-

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Manual
Coolant Capacity (qts)
380
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
