Huber 20-36 Light Four

Last Updated: June 2024

Overview

The Huber 20-36 Light Four is a standard-tread tractor built with a 4x2 2WD chassis and powered by a Waukesha gasoline engine with a 443 cubic inch displacement. The liquid-cooled 4-cylinder engine's specifications include a 4.75-inch bore and a 6.25-inch stroke. Equipped with a manual transmission offering 2 forward gears and 1 reverse, this model has classic features indicative of tractors from earlier periods of agricultural machinery design. Steering is manual, reflecting the simplicity and robust engineering of its time. The tractor's large steel wheels, with the front tires measuring 34 inches in diameter and the rear tires 50 inches, are designed to navigate a variety of terrains. At an operating weight of 6575 pounds and dimensions of 135 inches in length and 73 inches in width, the 20-36 Light Four is a solid workhorse likely intended for a range of farming tasks.
Show more...

Key Specifications

Category: Utility, Standard Tread

Transmission: Gear

Drive Type: 2WD

Operating Weight: 6575

Fuel Type: Gasoline

Huber 20-36 Light Four vs. Similar Tractors

Operating Weight
Average
Greater than 50% of similar tractors.

Technical Specifications

Engine

Manufacturer
Waukesha
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Gasoline
Induction Type
-
Cylinders
4
Displacement (ci)
443
Bore (in)
4.75
Stroke (in)
6.25
Rated RPM
-
Power Output (hp)
-

Transmission

Type
Gear
Forward Gears
2
Reverse Gears
1
Total Gears
-

Dimensions

Length (in)
135
Width (in)
73
Height (in)
-
Operating Weight (lb)
6575

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Manual
Coolant Capacity (qts)
-
Front Tire Diameter (in)
34
Front Tire Width (in)
-
Rear Tire Diameter (in)
50
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Steel
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
