Honda HF2620

Last Updated: June 2024

Overview

The Honda HF2620 is a 2WD lawn tractor that was part of Honda's HF series. Produced from 2004 to 2012, the HF2620 features a Honda GXV620 engine. It is a two-cylinder, air-cooled, natural aspirated gasoline engine with a displacement of 37.5 cubic inches. The engine has a bore of 3.03 inches, a stroke of 2.6 inches, and produces 20 horsepower at 2800 RPM. The tractor is built on a 4x2 2WD chassis and includes a belt-driven hydrostatic transmission with infinite forward and reverse gears. It also boasts manual steering, an open operator station with electric start, and a mid-mount mower deck measuring 48 inches. The HF2620 rides on lawn/turf tires, with fronts sized 15x6.00-6 and rears 18x8.50-8. Its operating weight is 538 pounds, and the tractor has a length of 73.2 inches and a steering wheel height of 44.1 inches. The detailing of the tractor highlights its suitability for maintaining lawns and gardens with relative ease and comfort. With a reasonable size and weight, the HF2620 is designed for efficiency and maneuverability in various lawn care tasks.
Show more...

Key Specifications

Category: Lawn and Garden

Power Output: 20

Transmission: Belt-driven hydrostatic

Drive Type: 2WD

Operating Weight: 538

Fuel Type: Gasoline

Honda HF2620 vs. Similar Tractors

Power Output
Average
Greater than 69% of similar tractors.
Operating Weight
Average
Greater than 35% of similar tractors.

Technical Specifications

Engine

Manufacturer
Honda
Model
GXV620
Cooling Type
Air-cooled
Cylinder Orientation
V-twin
Valve Configuration
-
Fuel Type
Gasoline
Induction Type
Natural aspirated
Cylinders
2
Displacement (ci)
37.5
Bore (in)
3.03
Stroke (in)
2.6
Rated RPM
2800
Power Output (hp)
20

Transmission

Type
Belt-driven hydrostatic
Forward Gears
Infinite
Reverse Gears
Infinite
Total Gears
-

Dimensions

Length (in)
73.2
Width (in)
-
Height (in)
44.1 (to the top of the steering wheel, actual overall height Unknown)
Operating Weight (lb)
538

Power Take-Off (PTO)

PTO Type
Independent with electro-magnetic clutch
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Manual
Coolant Capacity (qts)
-
Front Tire Diameter (in)
15
Front Tire Width (in)
6
Rear Tire Diameter (in)
18
Rear Tire Width (in)
8.5
Front/Rear Rim Diameter (in)
-
Tire Type
Lawn/turf
Manufacture - End Year
2012
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
Open
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
