Hinomoto E202

Last Updated: June 2024

Overview

The Hinomoto E202 is a compact utility tractor that is equipped with a robust Toyosha CS112 3-cylinder diesel engine capable of delivering 19.7 horsepower. Liquid-cooled to maintain operating efficiency, this engine provides a displacement of 68.7 cubic inches and runs at a rated RPM of 2500. This model features a transmission system with 6 forward and 2 reverse gears, allowing for versatile maneuvering in an array of farming tasks. With an operating weight of 1905 pounds, the Hinomoto E202 has substantial stability during operation, which is beneficial when working on a variety of landscapes. The tractor measures 108 inches in length, 48 inches in width, and 73 inches in height. Specific details on the tractor's chassis, wheel configuration, steering, and other component specifics are not provided in the available data.
Show more...

Key Specifications

Power Output: 19.7

Operating Weight: 1905

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
Toyosha
Model
CS112
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
3
Displacement (ci)
68.7
Bore (in)
2.953
Stroke (in)
3.347
Rated RPM
2500
Power Output (hp)
19.7

Transmission

Type
-
Forward Gears
6
Reverse Gears
2
Total Gears
-

Dimensions

Length (in)
108
Width (in)
48
Height (in)
73
Operating Weight (lb)
1905

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
-
Drive Type
-
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
