Hesston 60-56

Last Updated: June 2024

Overview

The Hesston 60-56, powered by a 60 hp Fiat 8035.05 diesel engine, is a utility tractor known for its ruggedness and simplicity. Featuring a 4x2 two-wheel drive chassis, this tractor is most suited for a variety of tasks on a small to medium-scale farm. The partially synchronized transmission with 12 forward and 3 reverse gears provides flexibility in handling various agricultural operations. It has a liquid-cooled three-cylinder engine with direct injection and a displacement of 178.9 cubic inches. Operating at a rated RPM of 2500, the tractor's gearbox and power allow for effective fieldwork. The tractor's notable measures include a 2WD length of 126 inches and a weight of 5105 lbs, indicating a durable and substantial build for demanding tasks. The 60-56 model features an open station with ROPS for the operator's protection and is fitted with agricultural tires to ensure appropriate traction in a variety of field conditions.
Show more...

Key Specifications

Category: Utility

Power Output: 60

Transmission: Partially Synchronized

Drive Type: 2WD

Operating Weight: 5105

Fuel Type: Diesel

Hesston 60-56 vs. Similar Tractors

Power Output
Average
Greater than 58% of similar tractors.
Operating Weight
Average
Greater than 44% of similar tractors.

Technical Specifications

Engine

Manufacturer
Fiat
Model
8035.05
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Direct Injection
Cylinders
3
Displacement (ci)
178.9
Bore (in)
4.094
Stroke (in)
4.528
Rated RPM
2500
Power Output (hp)
60

Transmission

Type
Partially Synchronized
Forward Gears
12
Reverse Gears
3
Total Gears
-

Dimensions

Length (in)
126 (2WD) / 129 (4WD)
Width (in)
-
Height (in)
93 (Exhaust)
Operating Weight (lb)
5105

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
II/I
Hitch Category
3
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
ROPS
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
