Goldoni 40A

Last Updated: June 2024

Overview

The Goldoni 40A is an Orchard/Vineyard tractor that is equipped with a 34 hp (25.4 kW) Lombardini diesel engine. It features an air-cooled 114.2 ci (1.9 L) engine with a rated RPM of 2800. The transmission is a 6-speed manual, including six forward gears and three reverse gears, complemented by a 215mm dry disc clutch. This model showcases Goldoni's dedication to developing tractors that meet the specific needs of orchard and vineyard operations, with a focus on maneuverability and efficiency. The tractor's articulated 4-wheel drive chassis ensures optimum traction and performance in varied terrain, typical of such agricultural environments. The steering wheel sits at a height of 49.2 inches (124 cm), whereas the total length of the tractor is 112.2 inches (284 cm). It is equipped with an electric starter system that runs on 12 volts. Though many specific details are unknown, based on available data, the 40A is a durable and capable machine for specialized farming operations.
Show more...

Key Specifications

Category: Agricultural, Orchard/Vineyard

Power Output: 34

Transmission: Manual

Drive Type: 4WD

Operating Weight: 2425

Fuel Type: Diesel

Goldoni 40A vs. Similar Tractors

Power Output
Poor
Greater than 9% of similar tractors.
Operating Weight
Below Average
Greater than 13% of similar tractors.

Technical Specifications

Engine

Manufacturer
Lombardini
Model
-
Cooling Type
Air-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
-
Displacement (ci)
114.2
Bore (in)
-
Stroke (in)
-
Rated RPM
2800
Power Output (hp)
34

Transmission

Type
Manual
Forward Gears
6
Reverse Gears
3
Total Gears
-

Dimensions

Length (in)
112.2
Width (in)
-
Height (in)
49.2 (heigh of steering wheel, overall height unknown)
Operating Weight (lb)
2425

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 articulated 4WD
Drive Type
4WD
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric Starter
Brake Type
-
Hydraulic System Type
-
