Goldini 70C

Last Updated: June 2024

Overview

The Goldini 70C is a compact utility tractor known for its robust 4-wheel drive (4x4 MFWD 4WD) configuration. Equipped with a VM Motori D754 diesel engine, it boasts a 181.2 cubic inch displacement with a bore and stroke measuring 3.70 inches and 4.21 inches respectively. This engine delivers a power output of 70 horsepower at a rated RPM of 2600 and offers a torque of 155.6 lb-ft at 1400 RPM. Its liquid-cooling system ensures the engine operates optimally under various working conditions. The tractor has a power steering type and a 16 forward plus 8 reverse speed manual transmission, providing versatility and control. The mechanical dry disc clutch further enhances the tractor's drivability. The standard agricultural tires are sized at 260/70R14 for the front and 360/70R24 for the rear, mounted on rims with diameters of 14 inches and 24 inches respectively. The Goldini 70C has a sturdy operating weight of 4519 pounds, making it suitable for a range of compact utility tasks. Additional specifications such as the tractor's dimensions and some specific features remain unlisted. Nonetheless, the 70C is built to offer reliability and performance for various agricultural operations.
Show more...

Key Specifications

Category: Utility

Power Output: 70

Transmission: Manual

Drive Type: 4WD

Operating Weight: 4519

Fuel Type: Diesel

Goldini 70C vs. Similar Tractors

Power Output
Average
Greater than 64% of similar tractors.
Operating Weight
Average
Greater than 41% of similar tractors.

Technical Specifications

Engine

Manufacturer
VM Motori
Model
D754
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Direct injection
Cylinders
4
Displacement (ci)
181.2
Bore (in)
3.7
Stroke (in)
4.21
Rated RPM
2600
Power Output (hp)
70

Transmission

Type
Manual
Forward Gears
16
Reverse Gears
8
Total Gears
-

Dimensions

Length (in)
-
Width (in)
-
Height (in)
-
Operating Weight (lb)
4519

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
9.5
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
14/24
Tire Type
Agricultural
Manufacture - End Year
-
Hitch Type
-
Hitch Category
II/I
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
