Foton 600

Last Updated: June 2024

Overview

The Foton 600 is a two-wheel drive (2WD) tractor that was designed to meet various agricultural needs. It is equipped with a 4-cylinder, liquid-cooled diesel engine, known as the R4105T12B, which has a power output of 61.7 horsepower and operates at a rated RPM of 2200. The engine features a displacement of 264.2 cubic inches, with a bore of 4.134 inches and a stroke of 4.921 inches, contributing to its robust performance and durability. The tractor's manual transmission offers 8 forward gears and 2 reverse gears, providing versatility in different farming operations. With a chassis configured as 4x2 2WD, it offers a balance of maneuverability and simplicity in operations. The Foton 600 measures 161.4 inches in length, 75.9 inches in width, and 107.1 inches in height, giving it a strong presence on the field, while its operating weight stands at 6,867 pounds. While specific details about the tire dimensions, hydraulic system, PTO speeds, and other features are not provided, this tractor's fundamental specifications show that it is designed for a range of agricultural tasks including plowing, planting, and harvesting.
Show more...

Key Specifications

Power Output: 61.7

Transmission: Manual

Drive Type: 2WD

Operating Weight: 6,867

Fuel Type: Diesel

Image Gallery

Technical Specifications

Engine

Manufacturer
Foton
Model
R4105T12B
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
4
Displacement (ci)
264.2
Bore (in)
4.134
Stroke (in)
4.921
Rated RPM
2200
Power Output (hp)
61.7

Transmission

Type
Manual
Forward Gears
8
Reverse Gears
2
Total Gears
-

Dimensions

Length (in)
161.4
Width (in)
75.9
Height (in)
107.1
Operating Weight (lb)
6,867

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag (Agricultural)
Manufacture - End Year
-
Hitch Type
-
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
