Ford-New Holland 2810

Last Updated: June 2024

Overview

The Ford-New Holland 2810 is a utility tractor designed for general farm and light-to-medium duty tasks. With a 34.3 horsepower, 3-cylinder diesel engine, it delivers enough power for efficient performance in a variety of applications. The engine is liquid-cooled to ensure optimal thermal regulation during heavy use, with a rated RPM of 2000 and a torque of 101 lb-ft, which peaks at 1400 RPM. Displacing 158 cubic inches, the engine's dual paper element air cleaner helps maintain clean combustion. The powertrain is complemented by a dual-range mechanical shuttle transmission with 8 forward and 2 reverse gears. As for its dimensions, the tractor measures 127.2 inches in length and 68.4 inches in width. This tractor stands out for its simplicity, solid construction, and longstanding reputation for reliability among farmers.
Show more...

Key Specifications

Category: Utility

Power Output: 34.3

Transmission: Mechanical shuttle

Drive Type: 2WD

Operating Weight: 4420 (for 2WD version)

Fuel Type: Diesel

Image Gallery

Ford-New Holland 2810 Tractor Ford-New Holland 2810 Tractor Ford-New Holland 2810 Tractor Ford-New Holland 2810 Tractor Ford-New Holland 2810 Tractor Ford-New Holland 2810 Tractor Ford-New Holland 2810 Tractor Ford-New Holland 2810 Tractor

Ford-New Holland 2810 vs. Similar Tractors

Power Output
Below Average
Greater than 30% of similar tractors.
Operating Weight
Above Average
Greater than 76% of similar tractors.

Technical Specifications

Engine

Manufacturer
Ford
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally aspirated (Assumption based on lack of any mention of turbocharging or supercharging)
Cylinders
3
Displacement (ci)
158
Bore (in)
4.2
Stroke (in)
3.8
Rated RPM
2000
Power Output (hp)
34.3

Transmission

Type
Mechanical shuttle
Forward Gears
8 forward (Assumed based on dual transmission types provided and common tractor configurations)
Reverse Gears
2 reverse (Assumed based on dual transmission types provided and common tractor configurations)
Total Gears
-

Dimensions

Length (in)
127.2
Width (in)
68.4
Height (in)
Unknown (Height can be assessed as 81.2 inches, which is the height with exhaust, as the tallest point)
Operating Weight (lb)
4420 (for 2WD version)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Manual
Coolant Capacity (qts)
11
Front Tire Diameter (in)
-
Front Tire Width (in)
6.00 (Assumed width based on provided standard tire info)
Rear Tire Diameter (in)
Unknown (Assumption based on common tire market offerings: 28 inches)
Rear Tire Width (in)
13.6 (Assumed width based on provided standard tire info)
Front/Rear Rim Diameter (in)
-
Tire Type
Ag (agricultural type)
Manufacture - End Year
-
Hitch Type
-
Hitch Category
Category I
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
Unknown (may be ROPS or cab depending on specific setup)
Starter Type
12 volt electric (Assuming starter type based on Engine - Starter volts)
Brake Type
-
Hydraulic System Type
Open center
