Ford FW-35

Last Updated: September 2024

Overview

The Ford FW-35 is a powerful utility tractor designed for heavy-duty farm work. It features a 4x4 articulated chassis with four-wheel drive, making it highly maneuverable in tough conditions. The tractor is equipped with a robust 6-cylinder diesel engine made by Ford. This engine produces an impressive 195 hp, which is very high compared to other tractors in its class. It has a large displacement of 401 ci, also well above average for similar models.

The FW-35 comes with a two-speed power shift transmission, offering 16 forward gears and 4 reverse gears. This gives operators plenty of options for different tasks. The tractor's three-point hitch is category III, suitable for handling large implements. It has a closed-center load sensing hydraulic system for efficient operation of attachments. The FW-35 is a big machine, measuring 260 inches long, 104 inches wide, and 133.7 inches tall. Its operating weight of 20,503 lb is very high, providing excellent stability for heavy work. With its combination of power, size, and features, the Ford FW-35 is well-suited for large-scale farming operations.
Show more...

Key Specifications

Category: Utility

Power Output: 195 hp (145.4 kW)

Transmission: Two-speed power shift

Drive Type: 4WD

Operating Weight: 20503 lb (9300 kg)

Fuel Type: Diesel

Ford FW-35 vs. Similar Tractors

Power Output

The Power Output for the Ford FW-35 is Excellent. It is greater than 94% of similar Utility tractors in our database.

Horsepower distribution of Utility tractors

(across 4.7K+ tractors in our database)

Operating Weight

The Operating Weight for the Ford FW-35 is Excellent. It is greater than 95% of similar Utility tractors in our database.

Operating weight distribution of Utility tractors

(across 4.4K+ tractors in our database)

Engine Displacement

The Engine Displacement for the Ford FW-35 is Above Average. It is greater than 90% of similar Utility tractors in our database.

Engine displacement distribution of Utility tractors

(across 1K+ tractors in our database)

Engine Rated RPM

The Engine Rated RPM for the Ford FW-35 is Below Average. It is greater than 28% of similar Utility tractors in our database.

Engine rated RPM distribution of Utility tractors

(across 1K+ tractors in our database)

Technical Specifications

Engine

Manufacturer
Ford
Cooling Type
Liquid-cooled
Fuel Type
Diesel
Cylinders
6
Displacement
401 ci (6.6 L)
Bore
4.40 in (111.8 mm)
Stroke
4.40 in (111.8 mm)
Rated RPM
2200
Power Output
195 hp (145.4 kW)

Transmission

Type
Two-speed power shift
Forward Gears
16
Reverse Gears
4

Drivetrain

Chassis
4x4 articulated 4WD
Drive Type
4WD
Steering Type
Articulated power
