Ford 6410 Mark III

Last Updated: June 2024

Overview

The Ford 6410 Mark III is a tractor model produced by Ford with a 2-wheel drive chassis. It is powered by a Ford 4-cylinder liquid-cooled diesel engine, boasting a displacement of 268.1 cubic inches and providing 80 horsepower at 2070 RPM. This particular model features a power steering system and a 16-speed transmission with 16 forward and 8 reverse gears. The tractor rides on a wheelbase that measures 87.4 inches and has a heft in the range of 7540 pounds for the 2WD variant to 8400 pounds for models equipped with 4WD. The Ford 6410 Mark III is equipped with standard ag tires, with front tires at 10.00-16 and rear tires at 16.9-34 dimensions. Overall lengths and height of the tractor are 116 inches and 106.3 inches, respectively. The Ford 6410 Mark III, with its robust construction and capable engine, is designed to handle a variety of agricultural tasks with efficiency and reliability.
Show more...

Key Specifications

Power Output: 80

Drive Type: 2WD

Operating Weight: 7540 (for 2WD)

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
Ford
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
4
Displacement (ci)
268.1
Bore (in)
4.4
Stroke (in)
4.4
Rated RPM
2070
Power Output (hp)
80

Transmission

Type
-
Forward Gears
16
Reverse Gears
8
Total Gears
24

Dimensions

Length (in)
116
Width (in)
-
Height (in)
106.3
Operating Weight (lb)
7540 (for 2WD)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
-
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric (based on starter volts info)
Brake Type
-
Hydraulic System Type
-
