Ford 1320

Last Updated: June 2024

Overview

The Ford 1320 is a versatile compact utility tractor that was produced by Shibaura for Ford as part of the Twenty Compact series from 1987 to 1998. It came with either a gear type transmission offering 9 forward and 3 reverse gears, or a hydrostatic transmission with infinite forward and reverse speeds. The three-cylinder liquid-cooled diesel engine provides 20 horsepower and features a 77.3 cubic inch displacement. Its open operator station is fitted with a two-post ROPS for safety. The tractor can be configured with either a 4x2 2WD or a 4x4 MFWD 4WD chassis and comes with power steering and wet disc brakes to enhance operating experience. Its three-point hitch with a lift capacity of 1,740 pounds enables the tractor to handle a variety of implements with ease.

Key Specifications

Category: Utility

Power Output: 20

Transmission: Gear or Hydrostatic

Drive Type: 2WD or 4WD

Operating Weight: 2115 (2WD) or 2230 (4WD)

Fuel Type: Diesel

Image Gallery

Ford 1320 Tractor

Ford 1320 vs. Similar Tractors

Power Output

Poor

Greater than 10% of similar tractors.

Hitch Capacity

Poor

Greater than 2% of similar tractors.

Operating Weight

Excellent

Greater than 94% of similar tractors.

Technical Specifications

Engine

Manufacturer: Shibaura
Model: J823
Cooling Type: Liquid-cooled
Cylinder Orientation: Inline
Valve Configuration: -
Fuel Type: Diesel
Induction Type: Naturally Aspirated
Cylinders: 3
Displacement (ci): 77.3
Bore (in): 3.23
Stroke (in): 3.15
Rated RPM: 2500
Power Output (hp): 20

Transmission

Type: Gear or Hydrostatic
Forward Gears: 9 (gear type) or Infinite (hydrostatic)
Reverse Gears: 3 (gear type) or Infinite (hydrostatic)
Total Gears: 9 forward and 3 reverse (gear type) or Infinite forward and reverse (hydrostatic)

Dimensions

Length (in): 112.2
Width (in): 58.7
Height (in): 82.3
Operating Weight (lb): 2115 (2WD) or 2230 (4WD)

Power Take-Off (PTO)

PTO Type: Transmission or live (option)
PTO Speed 1 (rpm): 540
PTO Speed 2 (rpm): 2000 (optional mid PTO)
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x2 2WD or 4x4 MFWD 4WD
Drive Type: 2WD or 4WD
Steering Type: Power
Coolant Capacity (qts): 4.2 (gear type) or 5.3 (hydrostatic)
Front Tire Diameter (in): -
Front Tire Width (in): -
Rear Tire Diameter (in): -
Rear Tire Width (in): -
Front/Rear Rim Diameter (in): -
Tire Type: Agricultural
Manufacture - End Year: 1998
Hitch Type: Three-Point Hitch
Hitch Category: I
Hitch Position: Rear
Hitch Capacity (lb): 1,740 lbs
Operator Station Type: Open operator station with two-post ROPS
Starter Type: Electric
Brake Type: Wet Disc
Hydraulic System Type: Open Center
