Fiat M100

Last Updated: June 2024

Overview

The Fiat M100 is a utility tractor known for its reliability and versatility on small farms and properties. This machine is equipped with a 2WD chassis and rides on standard agricultural tires. It provides power steering through a hydrostatic system, making maneuvering in tight spaces easier for operators. The tractor harnesses its strength from a New Holland Genesis 6-cylinder diesel engine, providing 100 hp at a rated RPM of 2200, with a displacement of 456 cubic inches. The cooling system capacity is 24.8 quarts, ensuring the engine stays at optimal temperatures. This tractor sports a partially synchronized transmission featuring 23 forward and 12 reverse gears, which gives the tractor flexibility in a variety of tasks. Standing 180 inches in length and 84 inches in width, it has a formidable presence but retains enough agility for efficient work. The operator can lift substantial loads with the rear three-point hitch, offering a maximum capacity of 16,530 pounds. While specific features like the manufacture year, PTO speeds, and operator station type are not provided, the Fiat M100 remains a competent tool for a range of agricultural purposes.
Show more...

Key Specifications

Category: Utility

Power Output: 100

Transmission: Partially synchronized

Drive Type: 2WD

Operating Weight: 11616 to 12606

Fuel Type: Diesel

Fiat M100 vs. Similar Tractors

Power Output
Above Average
Greater than 82% of similar tractors.
Hitch Capacity
Below Average
Greater than 14% of similar tractors.
Operating Weight
Excellent
Greater than 93% of similar tractors.

Technical Specifications

Engine

Manufacturer
New Holland
Model
Genesis
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally Aspirated (Assumed due to lack of forced induction data)
Cylinders
6
Displacement (ci)
456
Bore (in)
4.5
Stroke (in)
5
Rated RPM
2200
Power Output (hp)
100

Transmission

Type
Partially synchronized
Forward Gears
23
Reverse Gears
12
Total Gears
-

Dimensions

Length (in)
180
Width (in)
84
Height (in)
Unknown (Highest known measurement is 119.5 inches to top of exhaust, no data for overall height)
Operating Weight (lb)
11616 to 12606

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2
Drive Type
2WD
Steering Type
Hydrostatic power
Coolant Capacity (qts)
24.8
Front Tire Diameter (in)
-
Front Tire Width (in)
Unknown (Assuming approximately 11 inches based on tire specification "11.00-16")
Rear Tire Diameter (in)
Unknown (Assuming standard size for diameter 38 based on tire specification "18.4R38")
Rear Tire Width (in)
Unknown (Assuming approximately 18.4 inches based on tire specification "18.4R38")
Front/Rear Rim Diameter (in)
Unknown (Assumed to be 16" front and 38" rear based on tire specifications)
Tire Type
Agricultural
Manufacture - End Year
-
Hitch Type
Three-Point Hitch (Assumed from Rear Type II mentioned)
Hitch Category
Category 2 (Assumed from Rear Type II mentioned)
Hitch Position
Rear
Hitch Capacity (lb)
Max capacity 16,530 lbs
Operator Station Type
-
Starter Type
Electric (Assumed based on engine starter volts specified as 12)
Brake Type
-
Hydraulic System Type
Closed center load sensing
