Fiat 955C

Last Updated: June 2024

Overview

The Fiat 955C is an agriculture tractor designed with a robust and efficient setup. It comes equipped with a Fiat 8055 engine that provides 88 horsepower, which should be adequate for various medium-duty farm tasks. The engine features a liquid-cooling system to maintain optimal operating temperatures and prevent overheating during prolonged use. It uses direct injection technology, meaning fuel is injected directly into the combustion chamber, which generally allows for better fuel efficiency and performance. The rated RPM of the engine is 2500, and it's started electrically with a 12-volt system. The transmission is a gear-type with 8 forward and 4 reverse gears, coupled with a 304.8mm wet disc clutch, indicating the tractor should have sufficient control over speed and torque for different types of agricultural work. Its dry air cleaner system and pre-heating capabilities indicate it is designed to handle various weather conditions and improve engine start-up in colder climates. The tractor's width is 76.8 inches, and the length is 140.1 inches, with an operating weight of 13051 pounds. Data on the tire sizes and the exact chassis type was not provided, and assumptions for those details could not be made confidently. The Fiat 955C fits well into medium-scale farming needs and is likely to have been utilized in various farming operations such as tilling, plowing, and harvesting.
Show more...

Key Specifications

Power Output: 88

Transmission: Gear

Operating Weight: 13051

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
Fiat
Model
8055
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Direct injection
Cylinders
5
Displacement (ci)
279
Bore (in)
4.05
Stroke (in)
4.33
Rated RPM
2500
Power Output (hp)
88

Transmission

Type
Gear
Forward Gears
8
Reverse Gears
4
Total Gears
-

Dimensions

Length (in)
140.1
Width (in)
76.8
Height (in)
94.5 (height to exhaust)
Operating Weight (lb)
13051

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
-
Drive Type
-
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
III/II Opt
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
Open center
