Fiat 750S Special

Last Updated: September 2024

Overview

The Fiat 750S Special is a powerful tractor designed for serious farm work. It has a strong diesel engine made by Fiat, with four cylinders and 80 horsepower. This engine is liquid-cooled and uses direct injection for better fuel efficiency. The tractor runs at 2100 RPM and has a 12-volt electrical system with an electric starter.

This tractor offers great flexibility with its transmission. It has 14 forward gears and 4 reverse gears, giving a total of 18 gears to choose from. The transmission is partially synchronized and includes a creeper gear for slow, heavy-duty tasks. The 750S Special has manual steering and uses agricultural tires on both front and rear wheels. It also features a category II hitch, which is suitable for many farm implements. The hydraulic system is an open center type, common in many tractors.
Show more...

Key Specifications

Power Output: 80 hp (59.7 kW)

Transmission: Partially synchronized, creeper

Fuel Type: Diesel

Fiat 750S Special vs. Similar Tractors

Power Output

The Power Output for the Fiat 750S Special is Average. It is greater than 61% of similar Utility tractors in our database.

Horsepower distribution of Utility tractors

(across 6.6K+ tractors in our database)

Engine Displacement

The Engine Displacement for the Fiat 750S Special is Above Average. It is greater than 72% of similar Utility tractors in our database.

Engine displacement distribution of Utility tractors

(across 1K+ tractors in our database)

Engine Rated RPM

The Engine Rated RPM for the Fiat 750S Special is Below Average. It is greater than 18% of similar Utility tractors in our database.

Engine rated RPM distribution of Utility tractors

(across 1K+ tractors in our database)

Technical Specifications

Engine

Manufacturer
Fiat
Model
CO 3/70
Cooling Type
Liquid-cooled
Fuel Type
Diesel
Induction Type
Direct injection
Cylinders
4
Displacement
278 ci (4.6 L)
Bore
4.33 in (110.0 mm)
Stroke
4.72 in (119.9 mm)
Rated RPM
2100
Power Output
80 hp (59.7 kW)

Transmission

Type
Partially synchronized, creeper
Forward Gears
14
Reverse Gears
4
Total Gears
18
