Fiat 60-88

Last Updated: June 2024

Overview

The Fiat 60-88 is a utility tractor ideal for a variety of tasks in farming and light construction. It is powered by a three-cylinder Fiat 8035.05 diesel engine with a displacement of 165.4 cubic inches, producing 59.2 horsepower and a respectable torque output of 143.1 lb-ft at 1500 RPM. The tractor operates with a 12-volt electric starter system and a liquid cooling system, designed to handle rigorous workloads without overheating. It offers a shuttle and a creeper transmission type, featuring 20 forward and 8 reverse gears, which allow it to adapt to diverse working conditions. With a dry disc clutch and a significant transmission oil capacity of 49.0 liters, it can deal efficiently with prolonged periods of use. The Fiat 60-88 has a two-wheel-drive chassis and comes with power steering for ease of maneuverability. The cabin height is 99.5 inches, and the tractor's operating weight ranges between 6614 lbs for the 2WD variant and 7055 lbs for the 4WD option, indicating solid build quality suitable for demanding work environments.
Show more...

Key Specifications

Category: Utility

Power Output: 59.2

Transmission: Shuttle, Creeper

Drive Type: 2WD

Operating Weight: 6614 (2WD), 7055 (4WD)

Fuel Type: Diesel

Fiat 60-88 vs. Similar Tractors

Power Output
Average
Greater than 56% of similar tractors.
Operating Weight
Above Average
Greater than 79% of similar tractors.

Technical Specifications

Engine

Manufacturer
Fiat
Model
8035.05
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Direct injection
Cylinders
3
Displacement (ci)
165.4
Bore (in)
3.94
Stroke (in)
4.53
Rated RPM
2500
Power Output (hp)
59.2

Transmission

Type
Shuttle, Creeper
Forward Gears
20
Reverse Gears
8
Total Gears
-

Dimensions

Length (in)
133.5 (2WD), 137.6 (4WD)
Width (in)
-
Height (in)
99.5 (including cab height)
Operating Weight (lb)
6614 (2WD), 7055 (4WD)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural
Manufacture - End Year
-
Hitch Type
II/I
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
Cab
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
