Fiat 50-66

Last Updated: June 2024

Overview

The Fiat 50-66 is a utility tractor that operates with a 49.3 horsepower diesel engine provided by Iveco. Designated as 4x2 2WD, with a chassis indicating two rear driving wheels on a two-wheel-drive system, it ensures practical functionality for a range of agricultural tasks. With a power steering feature, the operability of this tractor under various conditions is enhanced. It boasts a transmission with 12 forward and 4 reverse gears, giving the operator ample control over speed and power output suitable for different tasks. The liquid-cooled Iveco 8035.06 engine provides reliability and efficiency. A wheelbase of 78.7 inches (2WD models) or 74.8 inches (4WD models) and a weight between 4255 and 4740 pounds underline its stability and sturdiness in the field. The tractor's dimensions are 127.6 inches in length, supporting a more compact design that enables maneuverability. Engine details like a 165.4 cubic inch displacement and a bore/stroke ratio of 3.94x4.53 inches are reflective of its capable powerplant.
Show more...

Key Specifications

Category: Utility

Power Output: 49.3

Drive Type: 2WD

Operating Weight: 4255 to 4740

Fuel Type: Diesel

Fiat 50-66 vs. Similar Tractors

Power Output
Average
Greater than 47% of similar tractors.
Operating Weight
Above Average
Greater than 87% of similar tractors.

Technical Specifications

Engine

Manufacturer
Iveco
Model
8035.06
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
3
Displacement (ci)
165.4
Bore (in)
3.94
Stroke (in)
4.53
Rated RPM
2500
Power Output (hp)
49.3

Transmission

Type
-
Forward Gears
12
Reverse Gears
4
Total Gears
-

Dimensions

Length (in)
127.6
Width (in)
-
Height (in)
-
Operating Weight (lb)
4255 to 4740

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
