Fendt Favorit 610S

Last Updated: June 2024

Overview

The Fendt Favorit 610S is a tractor designed primarily for agricultural use bearing the Fendt reputation for durability and performance. Equipped with a 2WD chassis and powered by an MWM D225-6 engine producing 85 horsepower at a rated RPM of 2300, it suits various tasks on the farm. The engine features six cylinders with a displacement of 317.3 cubic inches (5.2 L), moving within a 3.74-inch (95mm) bore and a 4.72-inch (120mm) stroke. This tractor has a 12-speed transmission with gears allocated as 12 forward and 6 reverse, hinting at its versatility in handling different work conditions. Standing at 100 inches (254 cm) in height with an overall length of 173.23 inches (440 cm), the Favorit 610S is designed to offer robustness for daily tasks. The tractor's wheelbase of 105.91 inches (269 cm) contributes to its stable operation. Distinctive tire size selections of 7.50-20 for the front and 18.4-34 for the rear demonstrate its readiness for varied terrain. The Favorit 610S weighs around 8775 pounds (3980 kg) in its 2WD configuration and can go up to 9503 pounds (4310 kg) for the 4WD variant. Specifics such as the starting system, PTO configuration, and hydraulic type remain undisclosed, but based on its era of manufacture and the provided engine and transmission details, we can depict the Favorit 610S as a reliable tractor for field work.
Show more...

Key Specifications

Power Output: 85

Drive Type: 2WD

Operating Weight: 8775 (2WD)

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
MWM
Model
D225-6
Cooling Type
-
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
6
Displacement (ci)
317.3
Bore (in)
3.74
Stroke (in)
4.72
Rated RPM
2300
Power Output (hp)
85

Transmission

Type
-
Forward Gears
12
Reverse Gears
6
Total Gears
-

Dimensions

Length (in)
173.23
Width (in)
-
Height (in)
100
Operating Weight (lb)
8775 (2WD)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
