Fendt Favorit 510C

Last Updated: June 2024

Overview

The Fendt Favorit 510C represents a multifaceted utility tractor that is designed to meet a range of agricultural needs. Its robust chassis supports a 4x4 MFWD 4WD drive system, ensuring strong performance in diverse terrain. The power steering and four-speed power shift transmission, offering a notable 44 gears, facilitate maneuverability and control. The tractor is powered by a 253.5 cubic-inch, turbocharged diesel engine from MWM, which delivers 105 horsepower at an optimal 2300 RPM. The liquid cooling system maintains engine efficiency and durability. It has a weight of 10,957 lbs and can support a maximum weight of up to 16,535 lbs, indicating a firm stance for both stationary work and heavy hauling. The Favorit 510C features a three-point hitch system with Category III/II compatibility allowing versatility in attachments and implements. This model encapsulates the robust and functional design characteristic of the Fendt brand, with a focus on performance and operator comfort.
Show more...

Key Specifications

Category: Utility

Power Output: 105

Transmission: Four-speed power shift

Drive Type: 4WD

Operating Weight: 10957

Fuel Type: Diesel

Fendt Favorit 510C vs. Similar Tractors

Power Output
Above Average
Greater than 84% of similar tractors.
Operating Weight
Average
Greater than 64% of similar tractors.

Technical Specifications

Engine

Manufacturer
MWM
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement (ci)
253.5
Bore (in)
4.13
Stroke (in)
4.72
Rated RPM
2300
Power Output (hp)
105

Transmission

Type
Four-speed power shift
Forward Gears
44
Reverse Gears
44
Total Gears
-

Dimensions

Length (in)
164.6
Width (in)
89.8
Height (in)
110 (Height of cab)
Operating Weight (lb)
10957

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Standard (ag)
Manufacture - End Year
-
Hitch Type
Three-Point Hitch
Hitch Category
III/II
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
Cab
Starter Type
Electric Starter
Brake Type
-
Hydraulic System Type
-
