Fendt Farmer 200S

Last Updated: June 2024

Overview

The Fendt Farmer 200S is a utility tractor featuring a 4x2 (2WD) chassis and powered by a KHD diesel engine. It has a liquid-cooled 3-cylinder engine with a displacement of 172.44 cubic inches and a power output of 40 hp at a rated RPM of 2000. The manual transmission boasts 13 forward gears and four reverse gears, supporting a variety of tasks on the farm. It sports a wheelbase of 77.56 inches (197 cm) contributing to stability and a comfortable ride. The dimensions of this tractor come at a length of 136.22 inches (345 cm) and a height of 90.16 inches (229 cm), with an operational weight of 4432 lbs (2010 kg). Although the starting and ending years of manufacture are not available, the nature of the specifications suggests the Farmer 200S would have been a good fit for farmers looking for a simple but robust machine for a variety of tasks including but not limited to ploughing, harrowing, and basic field work. The tire types are agricultural, suited for farm grounds with the front and rear tire specifications provided as 6.00-16 and 12.4-28 respectively. Despite the lack of data on certain specifications such as the steering type, starter type, and hydraulic system, the provided data offers a good snapshot of this tractor's capabilities and indicates that it was designed with utility and straightforward operation in mind.
Show more...

Key Specifications

Category: Utility

Power Output: 40

Transmission: Manual

Drive Type: 2WD

Operating Weight: 4432

Fuel Type: Diesel

Fendt Farmer 200S vs. Similar Tractors

Power Output
Average
Greater than 37% of similar tractors.
Operating Weight
Average
Greater than 40% of similar tractors.

Technical Specifications

Engine

Manufacturer
KHD
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
3
Displacement (ci)
172.44
Bore (in)
3.937
Stroke (in)
4.72
Rated RPM
2000
Power Output (hp)
40

Transmission

Type
Manual
Forward Gears
13
Reverse Gears
4
Total Gears
-

Dimensions

Length (in)
136.22
Width (in)
-
Height (in)
90.16
Operating Weight (lb)
4432

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2
Drive Type
2WD
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
