Fendt 314 Vario

Last Updated: June 2024

Overview

The Fendt 314 Vario is a versatile utility tractor equipped with a powerful AGCO Power engine and a unique continuously variable transmission known as Vario ML75. This tractor is designed to deliver a high level of productivity and comfort for a range of agricultural tasks. The 4-cylinder engine is turbocharged and intercooled, offering a rated power output of 130.1 hp and can reach up to 150.2 hp. At the heart of its performance, the engine operates at a rated RPM of 2100 while sustaining a peak torque of 479.4 lb-ft at 1500 RPM, capable of handling demanding workloads with ease. The tractor's 4WD chassis provides enhanced traction in various field conditions. The hydraulic system follows an open center design, vital for efficient operation of farm implements. Dimensionally, the tractor has a length of 170.7 inches, a width of 91.3 inches, and a cab height of 112.6 inches, sitting on a wheelbase of 95.3 inches and maintaining a ground clearance of 20.1 inches.
Show more...

Key Specifications

Category: Utility

Power Output: 130.1 (rated), 150.2 (maximum)

Transmission: Continuously Variable Transmission (CVT)

Drive Type: 4WD

Operating Weight: 11045

Fuel Type: Diesel

Fendt 314 Vario vs. Similar Tractors

Hitch Capacity
Excellent
Greater than 91% of similar tractors.
Operating Weight
Average
Greater than 64% of similar tractors.

Technical Specifications

Engine

Manufacturer
AGCO Power
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged intercooled
Cylinders
4
Displacement (ci)
268.4
Bore (in)
4.25
Stroke (in)
4.72
Rated RPM
2100
Power Output (hp)
130.1 (rated), 150.2 (maximum)

Transmission

Type
Continuously Variable Transmission (CVT)
Forward Gears
Infinite
Reverse Gears
Infinite
Total Gears
-

Dimensions

Length (in)
170.7
Width (in)
91.3
Height (in)
112.6 (cab height)
Operating Weight (lb)
11045

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Standard ag: Front: 480/65R24, Rear: 540/65R38 | Optional ag: Front: 16.9R24, Rear: 18.4R38
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
Max capacity: 18739 lbs
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
Open center
