Farmtrac 785DTC

Last Updated: June 2024

Overview

The Farmtrac 785DTC is an agricultural tractor designed for a variety of farming tasks. It comes equipped with a turbocharged diesel engine manufactured by Deutz-Fahr, featuring a liquid-cooling system and a displacement of 244 cubic inches, capable of delivering 85 horsepower. This tractor operates with a four-wheel-drive (4WD) chassis and a 4x4 MFWD configuration for improved traction and performance in diverse terrain. The hydrostatic power steering provides easy and precise control. This tractor uses a shuttle transmission with 15 forward and reverse gears, facilitating efficient field operations. The Farmtrac 785DTC has an operating weight of 7,490 pounds and dimensions that measure 158 inches in length, 82 inches in width, and 93 inches in height. The agricultural tires come in sizes of 13.6x24 for the front and 18.4x30 for the rear, providing a stable base for various activities. The tractor also includes a rear hitch with a Category II specification, but further details about lift capacity and hydraulic flow are not specified in the provided data.

Key Specifications

Category: Agricultural

Power Output: 85

Transmission: Shuttle

Drive Type: 4WD

Operating Weight: 7,490

Fuel Type: Diesel

Image Gallery

Farmtrac 785DTC Tractor

Farmtrac 785DTC vs. Similar Tractors

Power Output

Average

Greater than 63% of similar tractors.

Operating Weight

Poor

Greater than 6% of similar tractors.

Technical Specifications

Engine

Manufacturer: Deutz-Fahr
Model: -
Cooling Type: Liquid-cooled
Cylinder Orientation: -
Valve Configuration: -
Fuel Type: Diesel
Induction Type: Turbocharged
Cylinders: 4
Displacement (ci): 244
Bore (in): -
Stroke (in): -
Rated RPM: -
Power Output (hp): 85

Transmission

Type: Shuttle
Forward Gears: 15
Reverse Gears: 15
Total Gears: -

Dimensions

Length (in): 158
Width (in): 82
Height (in): 93
Operating Weight (lb): 7,490

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x4 MFWD 4WD
Drive Type: 4WD
Steering Type: Hydrostatic power
Coolant Capacity (qts): -
Front Tire Diameter (in): 24
Front Tire Width (in): 13.6
Rear Tire Diameter (in): 30
Rear Tire Width (in): 18.4
Front/Rear Rim Diameter (in): -
Tire Type: Agricultural
Manufacture - End Year: -
Hitch Type: Standard (Category assumed based on following specs)
Hitch Category: II
Hitch Position: Rear
Hitch Capacity (lb): -
Operator Station Type: -
Starter Type: Electric Starter (12 volts)
Brake Type: -
Hydraulic System Type: -
